Two-Cylinder Marine Air Breathing Apparatus Set with Full Face Mask
商品説明
について RHZKF-6.8×2/30 は two-cylinder self-contained breathing apparatus (SCBA) set designed for marine emergency response and other hazardous environments where smoke, toxic gas, steam, or oxygen-deficient air may be present. Supplied as a complete set with full face mask, harness, cylinders, pressure reducer, pressure gauge, and alarm system, it is intended to provide reliable respiratory protection for trained personnel during shipboard firefighting, rescue entry, inspection, and emergency operations.
これは marine air breathing apparatus stores compressed air in two 6.8L cylinders at 300 bar, providing a total air storage capacity of 4080L. The positive-pressure breathing system helps maintain safer breathing conditions inside the mask and supports effective use in contaminated atmospheres.
It is widely used in shipboard emergency response, shipbuilding, chemical handling, petroleum, metallurgy, power plants, warehouses, laboratories, mines, and rescue operations where respiratory hazards exist. For marine projects requiring compliance marking, the published model and certification details should always match the actual supplied product documents.
Standards & Compliance
- Product Type: Self-Contained Positive Pressure Air Breathing Apparatus
- Configuration: Twin-cylinder SCBA set
- Marine Marking: EC / MED / Ship’s Wheel Mark
- Note: Publish certification wording only when it matches the exact supplied model and approval documents
主な特徴
- Twin 6.8L cylinder configuration for higher total air reserve
- 300 bar working pressure for demanding emergency breathing tasks
- Full face mask with positive-pressure air supply
- Audible low-pressure alarm for timely exit warning
- Complete wearable SCBA set for shipboard and industrial emergency use
- こんな人に向いている smoke, toxic gas, vapor, and oxygen-deficient environments
技術仕様
| 項目 | 仕様 |
|---|---|
| モデル | RHZKF-6.8×2/30 |
| 製品タイプ | Twin-Cylinder SCBA Set |
| シリンダー容積 | 6.8L × 2 |
| Total Cylinder Volume | 13.6L |
| Air Storage Capacity | 4080L |
| Working Pressure | 300 bar |
| アラーム圧力 | 50–60 bar |
| Breathing Supply Type | Positive Pressure |
| Applicable Temperature | -30°C ～ +60°C |
| 相対湿度 | 0-100% |
| Ambient Pressure | 70–125 kPa |
| 梱包サイズ | 77 × 30 × 48 cm |
Working Principle
Compressed air stored in the cylinders passes through the cylinder valve and pressure reducer before entering the air supply system connected to the full face mask. The reducer lowers the cylinder pressure to the required medium-pressure level, and the demand valve supplies air according to the wearer’s breathing needs.
When the user wears the mask and opens the system, the apparatus delivers breathable air into the mask and maintains positive pressure to help reduce inward leakage from the outside environment. Exhaled air is discharged out of the system through the exhalation structure.
When cylinder pressure falls to the preset alarm range, the warning device activates to remind the wearer to leave the hazardous area. The manual supplementary air function should only be used when necessary or during inspection.
アプリケーション
- Shipboard firefighting and emergency response
- Entry into smoke-filled or oxygen-deficient compartments
- Engine room, cargo hold, and confined-space emergency operations
- Shipyard, offshore, and marine maintenance rescue support
- Chemical vapor or hazardous gas response
- Industrial inspection and standby rescue in high-risk environments
Available Models in the RHZK / RHZKF Series
| モデル | Cylinder Volume (L) | Working Pressure (MPa) | Air Storage (L) | Flow Rate (L/min) | Alarm Pressure (MPa) | Rated Duration (min) | Weight (kg) | Packing Size (cm) |
|---|---|---|---|---|---|---|---|---|
| RHZK-5/30 | 5 | 30 | 1500 | 300 | 5~6 | 50 | ≤12 | 77×30×48 |
| RHZK-6/30 | 6 | 30 | 1800 | 300 | 5~6 | 60 | ≤14 | 77×30×48 |
| RHZKF-2/30 | 2 | 30 | 600 | 300 | 5~6 | 20 | ≤4 | 77×30×48 |
| RHZKF-3/30 | 3 | 30 | 900 | 300 | 5~6 | 30 | ≤4.5 | 77×30×48 |
| RHZKF-6.8/30 | 6.8 | 30 | 2040 | 300 | 5~6 | 60 | ≤8.5 | 77×30×48 |
| RHZKF-6.8×2/30 | 13.6 | 30 | 4080 | 300 | 5~6 | 120 | ≤14.5 | 77×30×48 |
| RHZKF-9/30 | 9 | 30 | 2700 | 300 | 5~6 | 90 | ≤11.5 | 77×30×48 |
よくあるご質問
1. Why choose a twin-cylinder SCBA instead of a single-cylinder unit?
A twin-cylinder set provides a larger total air reserve, which is better suited to longer shipboard emergency tasks and high-risk entry work.
2. What is the working pressure of this marine SCBA set?
This model is listed with a 300 bar working pressure and a 50–60 bar low-pressure alarm range.
3. What is included in the complete SCBA set?
The set typically includes the cylinders, full face mask, harness, pressure reducer, pressure gauge, hoses, and alarm device.
4. Is this SCBA suitable for marine emergency response?
Yes. It is intended for shipboard environments where smoke, toxic gas, steam, or oxygen-deficient air may be present.
5. Can this unit be used outside marine applications?
Yes. It is also suitable for rescue, inspection, and respiratory protection tasks in industrial and hazardous gas environments.
